Security Turnstile Gate with 0.2s Barrier Open/Close Time RS-232 Communication Interface and 1-Way Operation Direction
Hubungi saya untuk sampel gratis dan kupon.
ApaAPP:0086 18588475571
Wechat wechat: 0086 18588475571
Skype: sales10@aixton.com
Jika Anda memiliki masalah, kami menyediakan 24 jam bantuan online.
xDetail produk
| Waktu buka penghalang | 0,2 dtk | Antarmuka komunikasi | RS-232, RS485 |
|---|---|---|---|
| Arah operasi | 1 arah | motor penghalang | Motor tanpa sikat |
| Tingkat perlindungan | IP54 | dimensi | 1200x990 MM |
| Panjang tongkat | 300MM (250-500MM opsional) | Berat | 150kg |
| Bahan kasus | SUS304# | Catu daya | AC220±10%V, 50HZ |
| Motor penggerak | Motor sikat DC (24V) | Antarmuka input | Sinyal Tingkat 12V |
| Kehidupan Layanan | 3 juta kali | Kecepatan transit | 30-40 orang/menit |
| Suhu operasi | -15 ° C hingga +75 ° C. | ||
| Menyoroti | 0.2s Barrier Open/Close Time Security Turnstile Gate,RS-232 Communication Interface Security Turnstile Gate,1-Way Operation Direction Security Turnstile Gate |
||
Deskripsi Produk
Security Mechanical Single Pole Access Control Barrier Gate
Our access control barrier gate is a high-tech product providing intelligent management to passageways. As an upgrade to intelligent tripod turnstiles and swing barriers, this product features fine processing with complete functions, making it ideal for high-level neighborhoods, intelligent buildings, hotels, subway stations, ports, and clubs.
Standard Technical Specifications
| Specification | Details |
|---|---|
| Dimensions | 1200mm (length) × 1000mm (height) |
| Stick Length | 300mm (optional range: 250-500mm) |
| Weight | 150kg |
| Case Material | Domestic standard SUS (304#) |
| Power Supply | AC220±10% V, 50HZ |
| Drive Motor | DC brushed motors (24V) |
| Service Life | 3 million cycles |
| Transit Speed | 30-40 people/minute |
| Operating Temperature | -15°C to +75°C |
Key Features and Functions
- Self-checking and alarm warning functions for easy maintenance
- Programmable operation modes via main board buttons
- Dual Anti-Pinch protection from both mechanical structure and induction
- Sound and light alarm functions for break-in and tag alerts
- Anti-rushing function with automatic stick locking
- Synchronizing function for single pole operation
- Automatic reset function with configurable timing
- Power-off automatic opening and power-on automatic closing
- Compatibility with various card reading equipment
- Remote control and management via computer interface
About Shenzhen Goldantell Technologies Co., Ltd
We are a leading exporter and supply chain service provider of intelligent turnstile and parking management products with over 8 years of experience. Our product range includes intelligent turnstiles, parking barriers, RFID cards, sentry boxes, wheel clamps, and related security access control systems. We've exported to more than 50 countries and established long-term partnerships with clients worldwide.
Our Certifications
Frequently Asked Questions
Can you install RFID card reader on the turnstile?
Yes, we can install RFID card reader systems, fingerprint reader systems, token systems, ESD systems, and more.
What is your warranty and after-sales service?
We offer a 12-month quality guarantee with professional English-speaking sales and after-sales support.
What are your lead times?
Standard items: 5-15 working days depending on quantity. Custom items require 3-10 additional working days.
Our Services
- 24-hour response to all inquiries
- Professional English-speaking support
- OEM services including custom logos and packaging
- Experienced engineering support
- Pre-sale consultation and post-sale guidance
Contact Information
Contact Person: Vivian Zhou
WhatsApp: +86 13699796334
WeChat: junziyouxin
Skype: goldantell02
Goldantell turnstiles - factory price, high quality, welcome your inquiry!
