Modern Automatic Barrier Gate with 550mm-600mm Passage Width 30-40 Persons/Min Pass Speed and IP54 Protection
Hubungi saya untuk sampel gratis dan kupon.
ApaAPP:0086 18588475571
Wechat wechat: 0086 18588475571
Skype: sales10@aixton.com
Jika Anda memiliki masalah, kami menyediakan 24 jam bantuan online.
xDetail produk
| Lebar bagian | 550mm-600mm | Lulus kecepatan | 30-40 orang/mnt |
|---|---|---|---|
| Catu daya | 100~240 V(AC) | Konsumsi Daya Max | 60w |
| Frekuensi | 50~60Hz | Perlindungan IP | IP54 |
| Suhu kerja | -15 ~ 75 ° C. | Dimensi tidak termasuk bar | 1200x280x1000 mm |
| Berat bersih | 65kg | Daya motor | 140W/24V |
| Kecepatan motorik | 1600r / mnt | Jarak komunikasi | ≤1200m |
| Ketebalan material | ≥1.5mm | Hidup berlari | 5-8 Juta siklus |
| Kelembaban relatif | ≤95%, Tanpa Kondensasi | ||
| Menyoroti | 550mm-600mm Passage Width Automatic Barrier Gate,30-40 Persons/Min Pass Speed Security Turnstile Gate,IP54 Protection Electric Retractable Gate |
||
Deskripsi Produk
New Styles Supermarket Entrance Automatic Barrier Electric Retractable Swing Open Security Control Gate
Premium automatic barrier electric retractable gate with advanced security control for supermarkets, parks, and parking lots.
Technical Specifications
| Parameter | Value |
|---|---|
| Power | AC 220 ±10% V, 50HZ |
| Operating Temperature | -15°C to 75°C |
| Relative Humidity | ≤95%, No Condensation |
| Access Width | ≤600mm |
| Passing Speed | 30-40 persons/min (IC Card) |
| Motor | 140W/24V |
| Motor Operation Speed | 1600R/Min |
| Communication Distance | ≤1200M |
| Material | SUS304, thickness ≥1.5mm |
| Running Life | 5-8 Million cycles |
| Protection Grade | IP54 |
Key Features
- Self-diagnosis and alarm function for easy maintenance
- Programmable operation via control panel
- Safety stop mechanism when obstruction detected
- Audible and visual alarms for security breaches
- Automatic locking system until opening signal received
- Adjustable arm synchronization
- Automatic reset function with adjustable timing
- Power failure protection - opens when power off, closes when power on
- Compatible with multiple access control systems (IC/ID cards, fingerprint, facial recognition, etc.)
- Available in unidirectional or bidirectional configurations
Customization Options
- Optional counter system
- Housing length options: 1.2m, 1.4m, or 1.6m
- Flap arm materials: acrylic glass, resin, PVC
- Flap arm colors: red, blue, yellow, colorless
About Shenzhen Goldantell Technologies
With over 8 years of experience, we are a leading manufacturer of intelligent turnstiles and parking management systems, exporting to more than 50 countries worldwide.
Frequently Asked Questions
Can you install RFID card reader on the turnstile?
Yes, we can install RFID card reader systems as well as fingerprint readers, token systems, ESD systems, and other access control solutions.
What is your warranty and after-sales service?
We provide 12-month quality guarantee with English-speaking support staff for all after-sales service needs.
What are your lead times?
Standard items: 5-15 working days depending on quantity. Custom items require 3-10 additional working days.
Trade Information
- Payment Methods: T/T, LC, Western Union, Escrow, PayPal
- Packaging: Carton box + wooden case/crate
- Shipping Options: Express (3-5 days), Air Cargo (2-7 days), Sea Freight (15-60 days)
- OEM Services Available: Custom designs, logo printing, packaging
Goldantell turnstiles - factory direct pricing, premium quality, contact us today for your security gate needs!
